Ocean-optics OTS User Manual

Optical Transmittance Spectrophotometer (OTS) Installation and Operation Manual Document Number OTS-00000-000-02-1008 Office: Ocean Opti

1: Introduction The following information and documentation also ships with the OTS:  Packing List The packing list is inside a plastic bag attac

Chapter 2 Installing the OTS Overview You must install the operating software application prior to connecting your OTS system to a computer. The O

2: Installing the OTS Measuring Transmittance To use the OTS to measure transmittance of lenses, windows, etc., be sure that light source cord is

2: Installing the OTS Correctly Adjusted Integration Time Incorrectly Adjusted Integration Time: Integration time set too high; part of spectrum i

2: Installing the OTS Incorrectly Adjusted Integration Time: Integration time set too low 5. When finished with setting parameters, close the Sca

2: Installing the OTS ► Measurement of Transmittance Procedure 1. Place a tint sample on the stage and click a button to acquire the spectra and

2: Installing the OTS ► Creating Reports Procedure By clicking the button, the information on the screen, including charts, data table, and samp

Chapter 3 Troubleshooting Overview The following sections contain information on troubleshooting issues you may encounter when using the OTS system.

3: Troubleshooting Note Improperly installed USB devices can also appear under the Universal Serial Bus Controller option. Be sure to check this loc

Appendix A Bulb Replacement Overview The OTS system contains the HL2000-HP-FSHA light source, which consists of a halogen bulb (Part No. HL-2000-H

Additional Offices: Ocean Optics Asia 666 Gubei Road, Kirin Tower, Suite 601B, Changning District, Shanghai, 200336 PRC Phone 86.21.6295.6600 Fax

B: Specifications Lamp Housing Connection BlockRear / Electronics Board Fan Wires HL-2000-FHSA Bulb Replacement Diagram 1. Unplug the power conne

B: Specifications 5. Remove the rear of the light source and remove the electronics mounting plate from the unit, taking particular care not to di

B: Specifications 9. Replace the bulb and reconnect the wires to the connection block. 10. Slide the lamp into the housing and secure the housing w

Index A Adobe Acrobat Reader, 4 B bulb part number, 13 replacement, 13 bulb replacement diagram, 14 C calibration, 6 D diagrams bulb replacement, 14

Index U upgrades, iii W warranty, iv Wavelength Calibration Data File, 4 Wavelength Calibration Data Sheet, 4 18 OTS-00000-000-02-1008

Table of Contents About This Manual ... iii D

Table of Contents Appendix A: Bulb Replacement...13 Overview ...

About This Manual Document Purpose and Intended Audience This document provides the user of the Optical Transmittance Spectrophotometer (OTS) with

About This Manual Warranty Our 3-Year Warranty, currently the best in the industry, covers the Ocean Optics miniature fiber optic spectrometer insi

Chapter 1 Introduction Product Overview The Ocean Optics Optical Transmittance Spectrophotometer (OTS) is a compact system consisting of a USB2000+

1: Introduction 2 OTS-00000-000-02-1008 About the System The OTS covers the 380-780 nm wavelength range and accepts samples from 10-150 mm in diamet

1: Introduction Software: Customized lens transmittance and color calculation software Quality: Conforms with ISO 8980-3, ISO 13666:1998, and CIE
